Description
The BNC Female Straight PCB/Panel Mount Jack is a versatile, industry-standard RF connector designed for reliable signal transmission in professional electronics. Featuring a high-quality bayonet-style coupling mechanism, this connector ensures a secure, rapid connection and disconnection, making it the ideal choice for applications that require frequent switching or modular hardware configurations.
Engineered for high-density electronic assemblies, this bulkhead-style jack allows for easy mounting through a chassis panel while providing a stable, through-hole solder connection to your PCB. The connector is constructed with a durable nickel-plated zinc alloy body, providing excellent environmental protection and corrosion resistance. Supporting both 50Ω and 75Ω system impedances, it delivers consistent, noise-free performance across a wide frequency range, making it essential for broadcast, telecommunications, medical, and security systems.
Features
- Design: BNC Female Jack, Straight (180°) orientation
- Mounting: Bulkhead panel mount with through-hole PCB termination
- Coupling: Bayonet-style quick-connect/disconnect mechanism
- Versatility: Compatible with both 50Ω and 75Ω impedance systems
- Build Quality: Nickel-plated zinc alloy body for long-term environmental protection
- Reliability: Engineered for ≥500 mating cycles and harsh environment resistance
Benefits
- Bulkhead design provides a solid, secure mounting point on equipment enclosures
- Bayonet locking mechanism prevents signal loss from accidental tugging or vibration
- Compact profile optimizes space on printed circuit boards
- High-grade materials provide excellent resistance to oxidation and wear
- Professional, OEM-quality build ensures optimal signal integrity
Applications
- Broadcasting, HDTV, and Video Recording Systems
- CCTV and Security Surveillance Equipment
- Telecommunications and Wireless Base Stations
- CATV and Satcom Infrastructure
- Medical Equipment and Industrial Instrumentation
- Antenna and Cable Assembly Integration
Package Includes
- 1 x Straight PCB Mount BNC Jack (Bulkhead)
Specifications
| Parameter | Specification |
|---|---|
| Brand | ElecBee |
| Orientation | Straight (180°) |
| Gender | Female (Jack) |
| Mounting Type | PCB / Panel Mount (Bulkhead) |
| Termination Style | Through-Hole Solder |
| Body Material | Zinc Alloy |
| Body Plating | Nickel Plating |
| Impedance | 50 Ω / 75 Ω |
| Operating Temperature | -55°C to +155°C (Teflon) |
| Shipping Weight | 0.01 kg |
