SPIDER Automation Waveshare Luckfox Pico Mini A RV1103 Linux Micro Development Board | ARM Cortex-A7 & NPU
Description
SPIDER Automation Waveshare Luckfox Pico Mini A RV1103 Linux Micro Development Board is a cutting-edge, miniature embedded development board designed for advanced AIoT, machine vision, and intelligent edge applications. Leveraging the Rockchip RV1103 system-on-chip, the board integrates a diverse multi-processor architecture combining a 1.2 GHz ARM Cortex-A7 32-bit core (with NEON and FPU), a self-developed 4th-generation NPU, a third-generation ISP3.2 image processor, and an auxiliary RISC-V microcontroller.
The board excels in intelligent video applications thanks to its powerful smart encoding engine, which saves over 50% of bitrate compared to conventional CBR modes while maintaining pristine HD image quality. With built-in 16-bit 64MB DDR2 DRAM, a MIPI CSI 2-lane camera interface, TF card storage support, and full Linux OS compatibility, the Luckfox Pico Mini A offers developers a versatile, ultra-compact platform for facial recognition, smart cameras, industrial automation, and custom IoT prototypes.
Key Features
- ARM Cortex-A7 Processor: High-performance 1.2 GHz 32-bit core with integrated NEON and FPU for general-purpose computing and Linux execution.
- Rockchip 4th-Gen NPU: Specialized Neural Processing Unit supporting int4, int8, and int16 hybrid quantization with up to 1.0 TOPS (int4) computing power.
- Advanced ISP3.2 Image Processor: Supports up to 4-megapixel cameras with hardware-level HDR, WDR, and multi-level noise reduction.
- Intelligent Video Encoding: Scene-adaptive stream saving technology that slashes bandwidth and storage requirements by over 50%.
- RISC-V Co-Processor: Low-power secondary MCU enabling rapid 250ms fast startup, instant image capture, and fast AI model loading.
- 64MB DDR2 Memory: Integrated 16-bit DRAM capable of sustaining demanding memory bandwidths for video streaming.
- Comprehensive Onboard Peripherals: Includes MIPI CSI 2-lane camera port, USB ports, built-in audio codec, MAC PHY, and TF card storage slot.
Benefits
- Edge AI Ready: Integrated NPU allows developers to run machine learning algorithms and facial recognition locally without cloud dependency.
- Ultra-Compact Footprint: Miniature board dimensions allow effortless physical integration into space-constrained enclosures and smart devices.
- Rapid Boot & Capture: RISC-V integration achieves sub-second camera activation and model loading for real-time security triggers.
- Robust Linux Environment: Full Linux OS support provides a flexible, developer-friendly software ecosystem with standard libraries and tools.
Applications
- Smart Security Cameras: Low-power AI surveillance cameras featuring local face recognition and motion-triggered snapshot capture.
- Machine Vision & Inspection: Automated optical inspection nodes utilizing high-speed ISP image processing and NPU object classification.
- IoT Edge Gateways: Connected sensor hubs running lightweight Linux services and telemetry data logging.
- Smart Home Appliances: Embedded video intercoms, smart doorbells, and interactive consumer electronics.
- Robotics & Drones: Compact visual navigation and target detection modules requiring low power and high processing density.
Package Includes
- 1 x Waveshare Luckfox Pico Mini A RV1103 Linux Micro Development Board (ARM Cortex-A7 / RISC-V / NPU / ISP)
Technical Specifications
| Parameter | Specification |
|---|---|
| Brand / Series | SPIDER Automation / Waveshare Luckfox Pico Series |
| Item Type | Linux Micro Development Board & Edge AI SBC |
| Model Name / SoC | Luckfox Pico Mini A / Rockchip RV1103 |
| Main Processor | Single-Core ARM Cortex-A7 (1.2 GHz) with NEON & FPU |
| Secondary MCU | Self-Developed RISC-V MCU (Low-Power & Fast Startup) |
| Neural Processing Unit (NPU) | 4th-Gen NPU (Up to 1.0 TOPS with int4, supports int8/int16) |
| Image Signal Processor (ISP) | ISP3.2 (Supports up to 4-Megapixel with HDR, WDR, Noise Reduction) |
| System Memory (RAM) | 64 MB DDR2 (16-bit DRAM) |
| Storage Interface | Mini A: TF (MicroSD) Card Slot (Card Not Included) |
| Camera Interface | MIPI CSI 2-Lane Support |
| USB Connectivity | 2 × USB Ports |
| Operating System Support | Linux OS |
| Package Shipping Weight | 0.015 kg (15 g) |
| Package Shipping Dimensions | 11 cm × 7 cm × 2 cm |
