Description
The WD100EW-03 is a 3-pin female housing connector built on a precise 1mm pitch platform. This assembly is pre-integrated with 300mm long 30 AWG gauge wire leads, providing a ready-to-use solution for compact electronic circuits.
Engineered to meet specific electrical requirements, it features an insulation impedance rating of 10 MΩ at 300V DC, which ensures stable signal transmission across the connector interface. This component is designed for applications where space-constrained housing and reliable, pre-terminated connectivity are critical for internal device architecture.
Key Features
- Connector Type: Female Housing Connector configuration for secure mating.
- Pitch: 1.0 mm precise spacing for high-density applications.
- Number of Pins: 3-pin standard layout.
- Wire Length: 300mm pre-cut leads for immediate integration.
- Wire Gauge: 30 AWG high-flexibility conductor.
- Insulation Impedance: 10 MΩ rating at 300V DC for signal integrity.
Applications
- Internal signal routing in compact consumer electronics.
- Sensor module connections in industrial control systems.
- Wiring for portable handheld devices and diagnostic equipment.
Package Includes
- 1 x JST-SH-1MM-3 pin Female Housing Connector with 300mm Wire (30 AWG)
Technical Specifications
| Parameter | Specification |
|---|---|
| Brand | Wenda Connectors |
| Connector Type | Female Housing Connector |
| Pitch | 1.0 mm |
| No. of Pins | 3 |
| Wire Length | 300 mm |
| Wire Gauge | 30 AWG |
| Shipping Weight | 0.005 kg |
| Shipping Dimensions | 5 × 5 × 1 cm |
