Description
The ICM7555IPAZ, manufactured by Renesas, is a high-performance RC timer IC built on advanced CMOS technology. Designed to be a drop-in, low-power alternative to the industry-standard 555 timer, it delivers precise timing capabilities with a maximum frequency of 1 MHz. Its flexible supply voltage range of 2V to 18V allows it to operate seamlessly in a wide variety of power configurations, making it an excellent choice for both battery-powered and mains-supplied electronic designs.
Housed in a standard 8-pin PDIP package, the ICM7555IPAZ is perfect for rapid prototyping, breadboarding, and straightforward PCB assembly. It is widely employed as a robust solution for oscillators, pulse generators, and various time-delay circuits, providing superior noise immunity and significantly lower power consumption than traditional bipolar 555 timers.
Key Features
- CMOS Technology: Provides low power consumption, high input impedance, and excellent noise immunity.
- High-Frequency Capability: Capable of stable operation at frequencies up to 1 MHz.
- Wide Voltage Range: Flexible supply operation from 2V to 18V for diverse design requirements.
- Industry-Standard Footprint: Standard PDIP-8 package ensures easy integration and compatibility with common design layouts.
- Versatile Applications: Ideal for use as an oscillator, pulse generator, or precision timer.
- Reliable Quality: Engineered by Renesas for consistent performance in demanding applications.
Applications
- Oscillators: Precise signal generation for clocking and system timing.
- Pulse Generators: Generation of stable pulse trains for control and signal processing.
- Time Delay Circuits: Reliable implementation of precise delays in automated systems.
- Embedded Designs: A staple timing component for general-purpose electronic hardware.
Package Includes
- 1 x ICM7555IPAZ RC Timer IC (PDIP-8)
Technical Specifications
| Parameter | Specification |
|---|---|
| Device | ICM7555IPAZ |
| Manufacturer | Renesas |
| Supply Voltage | 2V – 18V |
| Max Frequency | 1 MHz |
| Package Type | PDIP-8 |
| Operating Temp | -25°C to +85°C |
| Shipping Weight | 0.00001 kg |
| Shipping Dimensions | 5 × 4 × 1 cm |
Note: Product images are shown for illustrative purposes only and may differ from the actual product. For complete technical parameters, please refer to the official device datasheet.
