SPIDER Automation STMicroelectronics STM32F769I-DISCO Discovery Kit | STM32F769NI Evaluation Board
Description
SPIDER Automation STMicroelectronics STM32F769I-DISCO Discovery Kit is a highly advanced, feature-rich, and versatile evaluation platform designed for developing and testing complex microcontroller-based applications. At its center is the powerful STM32F769NI microcontroller, leveraging a high-speed ARM Cortex-M7 core with a double-precision floating-point unit (FPU), L1 cache, and advanced DSP instructions. Operating at speeds up to 216 MHz with 2 Mbytes of Flash memory, it handles heavy computational loads and graphics rendering with exceptional efficiency.
Equipped with a vibrant 4-inch capacitive touch screen display offering high resolution and a responsive touch interface, the kit allows users to create user-friendly graphical interfaces instantly. It also integrates robust networking options, including an IEEE-802.3-2002 compliant Ethernet port with Power over Ethernet (PoE) capability, USB OTG High-Speed, a Wi-Fi/Ext-EEP daughterboard connector, and an onboard SAI audio codec. Complete with an on-board ST-LINK/V2-1 debugger for easy programming and supported by major IDEs like Keil, IAR, and GCC-based toolchains (SW4STM32 and TrueSTUDIO), it delivers an all-in-one workstation for high-performance embedded design.
Key Features
- ARM Cortex-M7 Microcontroller Core: Powered by the high-performance STM32F769NI 32-bit RISC core featuring L1 cache, hardware FPU, and real-time control capabilities operating up to 216 MHz.
- 4″ Capacitive Touch LCD Display: Integrated high-resolution touchscreen panel providing a vibrant, responsive graphical interface ideal for advanced HMI prototyping.
- On-Board ST-LINK/V2-1 Debugger: Integrated debugging and programming circuit supporting USB virtual COM port, mass storage, and direct microcontroller debugging.
- Wi-Fi or Ext-EEP Daughterboard Connector: Dedicated expansion header allowing seamless integration of wireless communication modules and external EEPROM memory.
- USB OTG HS & SAI Audio Codec: Features a Micro-AB connector for High-Speed USB On-The-Go operations alongside an onboard SAI audio codec for multimedia applications.
- IEEE-802.3-2002 Compliant Ethernet: Built-in Ethernet controller enabling robust local network connectivity and internet communication for IoT edge devices.
- Multiple Power Supply Options (5 Ways): Supports powering via ST-LINK/V2-1, USB HS connector, 5V from RJ45 (PoE), Arduino/external connector, or a standard USB charger.
- Power over Ethernet (PoE) Support: Built-in IEEE 802.3af compliant module allowing the board to draw power directly through the Ethernet cable (powered device, 48V to 5V, 3W).
- Arduino Uno V3 Connectors & 3.3V/5V Outputs: Standardized connector headers offering compatibility with Arduino shields and providing external power supply outputs of 3.3V or 5V.
Benefits
- All-In-One HMI & Graphics Solution: Combines heavy processing power, a touch display, and audio peripherals on a single board, eliminating complex wiring setups.
- Flexible Powering & Deployment: Choose from 5 distinct power sources including PoE for remote industrial installations without separate power lines.
- Enterprise-Grade Software Compatibility: Fully supported by Windows OS (XP, 7, 8) and Linux 64-bit / OS X environments across major professional IDEs.
- Accelerated Time-to-Market: Robust out-of-the-box hardware eliminates initial PCB design overhead for industrial controllers and smart appliances.
Applications
- Industrial HMI & Smart Dashboards: Factory floor automation displays, machine telemetry monitors, and interactive control panels.
- IoT Edge Gateways & Network Nodes: Network-connected data aggregation hubs utilizing Ethernet and PoE deployments.
- Advanced Audio & Multimedia Devices: Networked audio streaming systems, voice-activated terminals, and digital signal processing units.
- Medical & Laboratory Equipment: Portable diagnostic display units, precision instrument controllers, and data logging terminals.
- Embedded Systems Education & Research: University labs teaching advanced ARM Cortex-M7 architecture, GUI design, and networked embedded systems.
Package Includes
- 1 x STMicroelectronics Discovery Kit with STM32F769NI MCU, On-Board ST-LINK/V2-1, and 4″ Capacitive Touch LCD Display
Technical Specifications
| Parameter | Specification |
|---|---|
| Brand / Series | SPIDER Automation / STMicroelectronics STM32F7 Discovery Series |
| Item Type | ARM Microcontroller Evaluation & Prototyping Discovery Kit (Kit) |
| Model Order Code / Number | STM32F769I-DISCO / STM32F769NI |
| Silicon Manufacturer & Family | STMicroelectronics / STM32F7 Series |
| Microcontroller Silicon | STM32F769NI (High-Performance 216 MHz MCU with 2MB Flash & RAM) |
| Core Architecture / Bits | 32-bit ARM Cortex-M7 RISC Processor Core with FPU and L1 Cache |
| Display Interface | 4-Inch Capacitive Touchscreen LCD Display Module (High Resolution) |
| Embedded Debugger | On-Board ST-LINK/V2-1 with Virtual COM Port & Mass Storage Support |
| Networking & Connectivity | 10/100 Ethernet (IEEE-802.3-2002), USB OTG HS (Micro-AB), Wi-Fi Header |
| Power Supply Capabilities | 5 Options including PoE (IEEE 802.3af, 48V to 5V, 3W), ST-LINK, USB, & External |
| Expansion & Peripherals | Arduino Uno V3 Connectors, SAI Audio Codec, Ext-EEP Daughterboard Header |
| Software & IDE Support | Windows / Linux / OS X; Keil, IAR, GCC-based IDEs (SW4STM32, Atollic TrueSTUDIO) |
| Package Shipping Weight | 0.217 kg (217 g) |
| Package Shipping Dimensions | 23 cm × 17 cm × 4 cm |
