Nano IO Shield V1.0 | Screw Terminal Adapter Expansion Board | For Arduino Nano v3.0 Microcontrollers
Description
The SPIDER Automation Nano IO Shield V1.0 is a professional-grade terminal adapter engineered to simplify wiring and enhance connection stability for Arduino Nano-based systems. By bridging the microcontroller with external sensors, actuators, and power circuits via heavy-duty screw terminals, this shield frees your projects from the limitations of traditional breadboard setups.
Optimized for Arduino Nano version 3.0 (and backward compatible with older versions while noting potential analog pin ordering differences like A0-A7), this compact breakout board ensures that every single pin is safely and securely accessible. It delivers the structural durability required for reliable electronic testing, custom control panels, and permanent embedded device deployments.
Key Features
- Comprehensive Pin Derivation: Breaks out all digital, analog, and power input/output pins into structured, accessible screw terminals.
- Heavy-Duty Screw Clamping: Firmly secures hookup wires to protect against signal interruption from vibration, tension, or accidental disconnections.
- Nano v3.0 Optimization: Fully aligned with standard Arduino Nano hardware layouts and legacy variant pin configurations.
- Compact Space-Saving Profile: Engineered with a minimal footprint to fit neatly inside custom enclosures and tight instrumentation spaces.
- Simplified Prototyping Workflow: Accelerates wiring and testing for educational labs, test benches, and R&D workstations without soldering directly to the board.
Benefits
- Guaranteed Signal Integrity: Screw-down connection terminals eliminate intermittent electrical faults caused by loose or frayed jumper wires.
- Rapid System Assembly: Allows engineers and developers to hook up external peripherals instantly without complex harness creation.
- Enhanced Enclosure Organization: Replaces tangled wire messes with clean, professional terminal routing inside control consoles.
-
Multi-Environment Utility: Essential interface adapter for automation prototyping, industrial testing rigs, and fixed installations.
Applications
- Embedded Control Panels: Centralized terminal interface for Arduino Nano-based automation and monitoring devices.
- Precision Electronic Test Benches: Secure signal and power routing for experimental circuits and diagnostic toolsets.
- Robotics & Sensor Interfacing: Rapid prototyping interface for custom hardware modules and environmental data collection arrays.
-
Field Maintenance & Upgrades: Reliable interface adapter for deploying quick hardware swaps and microcontroller fixes in machinery.
Package Includes
- 1 x SPIDER Automation Nano IO Shield V1.0
Specifications
| Item Type | Terminal Adapter / IO Expansion Shield |
| Brand / Series | SPIDER Automation |
| Model Type | DIY Nano IO Shield V1.0 |
| Compatibility | Arduino Nano v3.0 (Compatible with older variants with noted pin considerations) |
| Terminal Type | Standard Screw-Clamp Terminals |
| Pin Coverage | All Digital, Analog (A0–A7), and Power Pins Breakout |
| Board Dimensions | 52 × 36 × 15 mm |
| Board Weight | 20 g |
| Shipping Weight | 0.022 kg |
| Shipping Dimensions | 5 × 9 × 2 cm |
