SPIDER Automation Digilent Pmod Cable Kit | 6-Pin 6-Inch Extension & Gender Changer
Description
SPIDER Automation Digilent Pmod Cable Kit is engineered to overcome physical placement constraints and enhance flexibility when working with Digilent peripheral modules (Pmods) and development boards. Comprising a 6-inch (178mm) 6-pin extension cable and a matching 6-pin male gender changer, this kit gives engineers and makers the freedom to position modules outside of rigid board layouts.
Utilizing industry-standard 100mil spaced, 25mil square connectors, the cable kit guarantees seamless compatibility with all standard Pmod interfaces. Whether you are routing high-speed FPGA signals to external test setups, connecting sensors across an enclosure, or prototyping complex embedded systems, this kit delivers clean and reliable signal transmission.
Key Features
- Extended Reach: 6-inch (178 mm) cable length provides ample clearance for flexible component placement.
- Male Gender Changer Included: Expands connectivity options by converting pin genders for custom cable-to-cable linking.
- Standard 100mil Spacing: Features industry-standard 25mil square connectors compatible with standard pin headers.
- Signal Transmission: Reliable wiring designed for sending FPGA signals, power, and communication lines to outside devices.
Benefits
- Eliminates Layout Constraints: Move bulky or sensitive peripheral modules away from crowded development board headers.
- Simplified Prototyping: Instantly adapt and bridge connections without custom soldering or makeshift wiring.
- Universal Pmod Compatibility: Fully compatible with all Digilent Pmods and third-party development boards using standard 6-pin headers.
Applications
- FPGA Signal Prototyping: Tapping into FPGA I/O pins to interface with external breadboards, logic analyzers, or sensors.
- Enclosure Integration: Mounting Pmod displays or input modules on a project enclosure panel away from the main PCB.
- Laboratory & Educational Testing: Quick setup and tear-down of experimental circuits in academic and R&D labs.
Package Includes
- 1 x Digilent Pmod Cable Kit: 6-pin 6-inch Extension Cable
- 1 x 6-pin Male Gender Changer
Technical Specifications
| Parameter | Specification |
|---|---|
| Brand / Series | SPIDER Automation / Digilent Pmod Series |
| Item Type | Pmod Cable Kit & Extension Accessories |
| Model Order Code / SKU | Pmod Cable Kit / SKU-SPIDER-PMOD-CABLE-KIT |
| Compatibility | All Digilent Pmods and Standard 6-Pin GPIO / Interface Headers |
| Cable Length | 6 inches (178 mm) |
| Pin Count | 6 Pins |
| Connector Type | Standard 100mil Spaced, 25mil Square Connectors |
| Kit Inclusions | 1 × 6-Pin Extension Cable, 1 × 6-Pin Male Gender Changer |
| Physical Dimensions | 178 mm × 15 mm × 3 mm (Product Dimensions) |
| Product Weight | 12 g |
| Package Shipping Weight | 0.018 kg (18 g) |
| Package Shipping Dimensions | 26 cm × 17 cm × 1 cm |
