Description
The D-S Terminal Series DSW-06 Connector is a compact and durable electrical terminal connector designed to provide secure, stable, and reliable electrical connections in electronic, automotive, and industrial applications. Built for repeated use, it delivers excellent electrical performance with low contact resistance and high insulation resistance, ensuring dependable operation in demanding environments.
Rated for 30V DC and 0.5A, the DSW-06 connector is suitable for low-voltage signal transmission and control circuits. Its rugged construction supports up to 1000 mating cycles, making it ideal for applications requiring frequent connection and disconnection while maintaining consistent electrical performance.
Operating over a temperature range of -25°C to +70°C, this connector offers reliable performance in a wide variety of electronic equipment, industrial control systems, embedded devices, communication equipment, and testing applications.
Note: Product images are shown for reference only. The actual product may vary slightly in appearance, color, or manufacturer markings depending on production batch.
Features
- D-S Terminal Series DSW-06 connector
- Reliable low-voltage electrical connector
- Rated for 30V DC operation
- 0.5A current carrying capacity
- Low contact resistance for stable signal transmission
- High insulation resistance for improved electrical safety
- Dielectric withstand voltage of AC 250V
- Supports up to 1000 connection cycles
- Compact and durable construction
- Suitable for electronic, industrial, and automotive applications
Benefits
- Provides secure and reliable electrical connections
- Reduces signal loss through low contact resistance
- Ensures long service life with durable construction
- Supports repeated connection and disconnection
- Improves electrical safety with high insulation resistance
- Suitable for compact electronic assemblies
- Easy integration into low-voltage systems
- Reliable operation across a wide temperature range
Applications
- Industrial Automation Equipment
- Electronic Control Systems
- Communication Equipment
- Automotive Electronics
- Embedded Electronics
- PCB Assemblies
- Signal Transmission Circuits
- Instrumentation Equipment
- Testing and Measurement Devices
- Development Boards
- Control Panels
- Electronic Prototyping
- DIY Electronics Projects
- Smart Electronic Devices
- Consumer Electronics
- Industrial Monitoring Systems
- Electronic Repair Applications
- Automation Projects
- Low Voltage Electrical Connections
- General Wire-to-Connector Applications
Package Includes
- 1 x D-S Terminal Series DSW-06 Connector
Specifications
| Parameter | Specification |
|---|---|
| Product Name | D-S Terminal Series DSW-06 Connector |
| Model | DSW-06 |
| Rated Voltage | 30 V DC |
| Rated Current | 0.5 A |
| Contact Resistance | ≤ 0.03 Ω |
| Insulation Resistance | ≥ 100 MΩ |
| Withstand Voltage | AC 250V (50Hz) / 1 Minute |
| Operating Temperature | -25°C to +70°C |
| Mechanical Life | 1000 Mating Cycles |
| Shipping Weight | 0.005 kg |
| Shipping Dimensions | 12 × 8 × 2 cm |
