Description
The Littelfuse 02163.15MXP is a high-performance fast-acting glass body cartridge fuse from the renowned 216 series. Engineered for rapid response, this fuse is designed to provide immediate protection against short circuits and overcurrent conditions in electronic appliances and equipment.
With its standardized 5mm x 20mm form factor and 250V rating, this fuse is an ideal choice for safeguarding sensitive components where quick circuit interruption is required. Built to Littelfuse’s exacting standards, the 02163.15MXP offers a reliable 1.5kA breaking capacity, ensuring that your circuits remain protected even under high-fault current scenarios.
Key Features
- Fast-Acting Response: Specifically designed to react instantly to faults, providing rapid disconnection for sensitive electronic circuitry.
- Industry-Standard Size: The 5x20mm glass cartridge design ensures universal compatibility with standard fuse holders and panel-mount clips.
- High Breaking Capacity: Features a 1.5kA AC breaking capacity, delivering robust safety performance during severe overcurrent events.
- Professional Quality: Manufactured by Littelfuse to ensure consistent electrical characteristics and long-term operational reliability.
Package Includes
- 1 x Littelfuse 02163.15MXP Fast-Acting Cartridge Fuse (3.15A)
Technical Specifications
| Parameter | Specification |
|---|---|
| Part Number | 02163.15MXP |
| Fuse Type | Cartridge Fuse (216 Series) |
| Current Rating | 3.15A |
| Voltage Rating | 250V AC |
| Blow Characteristic | Fast Acting |
| Fuse Dimensions | 5 x 20 mm |
| Breaking Capacity | 1.5kA AC |
