Product Description
The AI-5600 is a non-contact handheld infrared thermometer designed for quick and accurate surface temperature measurements. With a rugged build and laser targeting, it is ideal for industrial, electrical, and HVAC applications. The device features a backlit LCD screen for clear readings in various lighting conditions and provides user-friendly operation with adjustable settings.
Key Features
- Non-contact temperature measurement
- Built-in laser pointer for accurate targeting
- Large backlit LCD display
- Fast response time
- Ergonomic design for one-handed operation
- Adjustable emissivity
- Max, Min, and Avg temperature display
- °C/°F selectable
- Data hold function
- Auto power-off to conserve battery
- Battery low indication
Specifications
| Parameter | Value |
| Model | AI-5600 |
| Temperature Range | -50°C to 1050°C (-58°F to 1922°F) |
| Accuracy | ±1.5% of reading or ±1.5°C |
| Repeatability | ±1% of reading or ±1°C |
| Distance Spot Ratio | 30:1 |
| Emissivity | Adjustable (0.10 to 1.00) |
| Resolution | 0.1°C / 0.1°F |
| Response Time | < 500 ms |
| Spectral Response | 8–14 µm |
| Operating Temperature | 0 to 50°C (32 to 122°F) |
| Storage Temperature | -20 to 60°C (-4 to 140°F) |
| Power Supply | 9V Battery |
| Dimensions | Approx. 153 × 101 × 43 mm |
| Weight | Approx. 200g (including battery) |
Applications
- Electrical and mechanical maintenance
- HVAC system diagnostics
- Automotive diagnostics
- Food safety inspections
- Laboratory temperature monitoring
PDF: https://www.yudian.com.hk/app/download/7246066404/HandheldThermometerAI5600r5.pdf
