SPIDER Automation UNIHIKER M10 IoT Python Single Board Computer | 2.8″ Touchscreen & Sensors
Description
SPIDER Automation UNIHIKER M10 is a compact yet powerful single-board computer that redefines embedded hardware development and educational coding. Featuring a vibrant 2.8-inch touchscreen, built-in Wi-Fi, Bluetooth, and an array of environmental and motion sensors—including a light sensor, accelerometer, gyroscope, and microphone—it provides an all-in-one platform for rapid prototyping and IoT projects.
Driven by a built-in co-processor, the UNIHIKER M10 effortlessly communicates with a wide range of analog, digital, I2C, UART, and SPI sensors and actuators through standard Gravity 3-pin and 4-pin ports or the edge connector. Pre-installed software environments like Jupyter Notebook enable developers to program the device directly from a smartphone or tablet browser, while traditional editors like VS Code, VIM, and Thonny are fully supported under a Debian operating system.
Key Features
- Quad-Core Processor: Powered by an ARM Cortex-A35 quad-core CPU operating up to 1.2 GHz.
- Memory & Storage: Equipped with 512MB RAM and 16GB Flash memory for smooth operating system performance.
- 2.8-Inch Touch Display: Integrated color touchscreen (240×320 resolution) for interactive graphical user interfaces.
- Onboard Environmental & Motion Sensors: Features a built-in light sensor, accelerometer, gyroscope, and microphone.
- Co-Processor Architecture: Dedicated co-processor handles peripheral communication with external modules and sensors.
- Browser-Based Programming: Pre-installed Jupyter Notebook allows coding directly via web browsers on mobile or desktop devices.
- PinPong Control Library: Enables direct Python control of onboard sensors and hundreds of connected actuators.
- Built-In SIoT Service: Store and manage data locally using the MQTT protocol with real-time web data access support.
- Flexible Connectivity: Includes USB Type-C, USB-A ports, Gravity interface headers, an edge connector, Wi-Fi, and Bluetooth.
Benefits
- Zero-Configuration Startup: Pre-installed software environments let users start coding within minutes without complex toolchain installations.
- All-In-One IoT Solution: Combines display, input sensors, wireless networking, and local data logging in a single pocket-sized unit.
- Versatile Development Workflow: Supports mobile/tablet browser coding as well as professional desktop IDEs like VS Code and Thonny.
Applications
- STEM Education & Coding Classes: Perfect platform for teaching Python programming, IoT concepts, and physical computing to students.
- Smart Home Control Panels: Designing interactive touch-screen interfaces to monitor and control household IoT appliances.
- Environmental Monitoring Stations: Utilizing onboard light, motion, and external sensors to log and display real-time sensor data.
- Wearable & Portable Gadgets: Compact form factor ideal for handheld instrument prototyping and mobile sensor logging.
- MQTT Data Logging Hubs: Deploying local IoT dashboards using the built-in SIoT service and MQTT broker capabilities.
- Robotics & Automation Prototyping: Interfacing motors, servos, and digital/analog sensors via Gravity connectors and Python libraries.
Package Includes
- 1 x UNIHIKER M10 – IoT Python Single Board Computer with Touchscreen
Technical Specifications
| Parameter | Specification |
|---|---|
| Brand / Model Series | SPIDER Automation / UNIHIKER Series (M10) |
| Item Type | Single Board Computer (SBC) / IoT Development Board |
| Central Processing Unit (CPU) | Quad-Core ARM Cortex-A35 (Up to 1.2 GHz) |
| System Memory (RAM) | 512 MB |
| Flash Storage Memory | 16 GB eMMC Flash |
| Operating System (OS) | Debian Linux |
| Screen Display | 2.8-Inch Color Touchscreen (240 × 320 Resolution) |
| Wireless Connectivity | Wi-Fi & Bluetooth Integrated |
| Onboard Sensors | Light Sensor, Accelerometer, Gyroscope, and Microphone |
| Software Environments | Jupyter Notebook, VS Code, VIM, Thonny, PinPong Library, SIoT MQTT Service |
| Device Ports & Interfaces | USB Type-C, USB-A Port, Gravity 3-Pin & 4-Pin Ports, Edge Connector |
| Power Supply Rating | 5V DC @ 2A via USB Type-C Port |
| Shipping Net Weight | 0.2 kg |
