TXB0108 8-Bit Bidirectional Voltage-Level Translator with Auto-Direction Sensing and ±15-kV ESD Protection – TSSOP-20 Package

Description

The TXB0108 is a high-performance, 8-bit non-inverting voltage level translator designed to enable seamless communication between devices operating at different voltage domains. Featuring auto-direction sensing, this device eliminates the need for a separate direction control pin, simplifying complex bus-level shifting designs. With two independent, configurable power-supply rails, VCCA (1.2V to 3.6V) and VCCB (1.65V to 5.5V), it provides universal bidirectional translation for a vast range of logic nodes including 1.2V, 1.5V, 1.8V, 2.5V, 3.3V, and 5V systems.

Built for reliability in demanding environments, the TXB0108 includes robust ESD protection up to ±15kV and an I_OFF feature that supports partial power-down mode, preventing damaging back-flow current when the device is unpowered. Whether used in high-speed communication interfaces, consumer smartphones, or industrial PC peripherals, the TXB0108 delivers consistent performance with ultra-low power consumption. Its compact TSSOP-20 package is perfectly suited for modern, high-density PCB layouts.

Key Features

• 8-Bit Bidirectional Translation: Full 8-channel translation with automatic direction sensing for simplified interface design.
• Wide Voltage Compatibility: Supports VCCA (1.2V to 3.6V) and VCCB (1.65V to 5.5V) for universal logic level shifting.
• Advanced ESD Protection: Industry-leading protection up to ±15kV Human-Body Model (HBM) on critical ports.
• Low Power Consumption: Highly efficient operation with a maximum ICC of just 4μA.
• VCC Isolation: Outputs automatically enter high-impedance state if either power rail is at GND.
• Partial Power-Down Support: I_OFF circuitry prevents current back-flow during unpowered states.
• Compact TSSOP-20 Package: Small form factor optimized for space-constrained industrial and consumer electronic designs.

Applications

• Mobile Devices: Essential for signal level translation in Smartphones, Tablets, and Handsets.
• Computing: Reliable interfacing for Desktop PC communication buses and peripheral devices.
• Embedded Systems: Bridging logic levels between low-voltage sensors, processors, and high-voltage peripherals.
• Industrial Electronics: High-reliability translation for automated control and data logging systems.

Package Includes

• 1 x TXS0108EPWR 8-Bit Bidirectional Voltage-Level Translator (TSSOP-20)

Technical Specifications

Note: Product images are shown for illustrative purposes only and may differ from the actual product. “YF08E” printed on the IC does not affect the product’s functionality. For complete electrical characteristics, pin assignments, and application design guides, please refer to the official Texas Instruments datasheet.
