Description
The TK-045C Tact Switch (4.5×4.5mm) is a versatile, high-precision input component designed for a wide range of electronic and consumer applications. Engineered to provide a crisp, distinct “click” with every actuation, this switch ensures clear user feedback, making it ideal for devices where tactile reliability is essential. Its robust construction features silver-plated contacts for excellent conductivity and insert-molded terminals that prevent flux contamination during the soldering process.
The TK-045C is built for flexibility and ease of integration, featuring a snap-in mounting terminal and an optional ground terminal for enhanced stability and electrostatic protection. Whether you are designing compact audio-visual products, medical equipment, or high-use remote controls, the TK-045C offers the durability (rated for 100,000 cycles) and performance required for professional-grade hardware.
Note: Product images are for reference only. The actual product may vary slightly in appearance or manufacturer markings depending on stock availability.
Key Features
- Compact 4.5×4.5mm Profile: Space-efficient design optimized for high-density electronic assemblies.
- Superior Tactile Feedback: Calibrated to provide a crisp, satisfying click that ensures accurate input confirmation.
- Flux-Resistant Design: Insert-molded terminals effectively prevent flux from rising into the switch mechanism during assembly.
- Flexible Mounting: Available in both vertical and right-angle thru-hole configurations to suit various board layouts.
- Professional Contact Quality: Features silver-plated contacts for low resistance and high reliability.
- Robust Stability: Includes a snap-in mount and an attached ground terminal for secure PCB retention.
- Versatile Force Options: Available in multiple operating force variants (100gf, 160gf, or 250gf ±50gf).
Benefits
- Production Efficiency: Flux-prevention design reduces rework and improves assembly yields in high-volume production.
- Signal Integrity: Low contact resistance (≤100mΩ) ensures consistent performance across complex control circuits.
- Design Versatility: The combination of vertical/right-angle options and ground-terminal integration simplifies board-level routing.
- End-User Satisfaction: The high-quality tactile response elevates the perceived build quality of the finished product.
- Long-Term Reliability: Built to withstand 100,000 operational cycles in diverse environmental conditions (-10°C to 70°C).
Applications
- Consumer Electronics: Perfect for audio-visual equipment, digital devices, and remote controls.
- Medical & Fitness: Reliable input for medical diagnostic equipment and professional fitness hardware.
- Home & Office: Ideal for white goods, household appliances, and computer peripherals.
- Security & Communication: Trusted component for security systems, communication products, and access control modules.
- Hobbyist/Niche Gear: Commonly used in toys, laser pointers, and currency detection devices.
Package Includes
- 1 x Tact Switch-TK-045C-4.5×4.5mm
Specifications
| Parameter | Specification |
|---|---|
| Model | TK-045C |
| Dimensions | 4.5 × 4.5 mm |
| Rated Voltage | 12V DC |
| Operating Force | 160gf, 260gf (± 50gf) |
| Mechanical Lifespan | 100,000 Cycles |
| Contact Resistance | ≤ 100mΩ |
| Insulation Resistance | ≥ 100MΩ |
| Operating Temperature | -10°C to 70°C |
| Shipping Weight | Approx. 0.001 kg |
