Description
The SkyRC eFuel 1200W Power Supply is an advanced, high-capacity benchtop power unit engineered to feed power-hungry high-end chargers and workshop equipment. Featuring an adjustable DC output voltage from 15V to 30V and a massive 50A continuous output capacity (up to 1200W total), the eFuel is built to handle heavy-duty multi-channel charging rigs with absolute ease.
Equipped with Active Power Factor Correction (PFC) for maximum grid efficiency and worldwide compatibility via universal AC input (100–240V), it is generator-friendly and generates minimal electrical interference. The unit features one heavy-duty main DC output (up to 50A) alongside three auxiliary switched output channels (up to 10A each) with individual ON/OFF controls, dual 5V 2.1A USB charging ports, and a bright digital LCD readout showing real-time voltage and current. Protected by a comprehensive safety suite and an automatic smart cooling fan, it is the ultimate power hub for your workshop or pit station.
Note: Product images are for reference only; actual appearance, AC power cords, or packaging may vary slightly based on manufacturing batches.
Key Features
- Massive 1200W Power Output: Delivers up to 50 Amps of continuous DC power to run heavy-duty chargers and demanding workshop gear simultaneously.
- Adjustable Voltage Control: Easily dial in your exact required DC voltage anywhere from 15.0V to 30.0V using the front control knob.
- Multi-Port Output Distribution: Features one main 50A output terminal plus three auxiliary banana-plug output channels (up to 10A each) with individual ON/OFF switches.
- Active Power Factor Correction (PFC): Advanced circuit design achieves over 98% power efficiency, minimizes harmonic distortion, and ensures stable generator compatibility.
- Universal AC Input: Operates safely anywhere in the world on 100–240V AC mains without requiring manual voltage selection switches.
- Dual USB Charging Ports: Integrated 5V 2100mA USB outputs for keeping smartphones, tablets, and accessories charged at your bench.
- Real-Time Digital LCD Readout: Clearly displays output voltage and current draw at a glance.
Benefits
- Centralized Workbench Power: Run multiple high-power battery chargers and DC accessories from a single, robust desktop power station.
- Generator Friendly: Active PFC technology prevents tripping and voltage instability when running your pit setup off portable outdoor generators.
- Safe & Reliable Operation: Multi-layer protection guards against over-temperature, over-voltage, over-current, overloading, and short-circuits.
Applications
- High-Power RC Charging Stations: Perfect power source for dual-port and quad-port heavy-duty desktop battery chargers operating at maximum wattage.
- Pit & Workshop Power Hub: Run tire warmers, soldering stations, DC lights, and test equipment simultaneously from one consolidated unit.
- Electronics Testing Bench: Adjustable voltage range makes it an exceptional variable DC power supply for DIY electronics and bench testing.
Package Includes
- 1 x SkyRC eFuel 1200W Power Supply
- 1 x AC Power Cord
- 1 x User Manual / Quick Guide
Specifications
| Parameter | Specification |
|---|---|
| Item Type | Adjustable DC Bench Power Supply with Active PFC |
| Manufacturer / Brand | SkyRC |
| Model Name | eFuel 1200W |
| AC Input Voltage Range | 100 – 240V AC, 50 / 60Hz (Worldwide Compatible) |
| DC Output Voltage Range | 15.0V – 30.0V DC (Adjustable, ±0.5V) |
| Max Output Current & Power | 50A ± 1A (Up to 1200W Total) |
| Output Channels | 1 × Main DC Output (Up to 50A) 3 × Auxiliary Outputs with ON/OFF Switch (Up to 10A each) |
| USB Charging Ports | 2 × 5.0V USB Ports (2100mA total output) |
| Power Efficiency & Factor | Efficiency: 89% | Power Factor (PFC): >0.98 |
| Display Type | Backlit Digital LCD Readout (Voltage & Current) |
| Cooling System | Smart Cooling Fan (Activates automatically at 50°C) |
| Safety Protections | Over-Temperature (>65°C), Over-Voltage, Overload, Short-Circuit Protection |
| Net Weight / Shipping Weight | 3.0 kg (3,000 g) |
| Shipping Dimensions | 42 × 13 × 13 cm |
