Description
The SafeConnect Twisted Servo Lead Extension is a professional-grade wiring solution engineered for high-performance RC aircraft and robotic applications where electrical efficiency and structural durability are paramount. Unlike standard, thinner gauge servo wires, this 22AWG twisted cable is specifically designed to handle higher current loads, making it an ideal choice for larger RC planes utilizing servos that experience significant mechanical resistance or high-draw operation.
Each lead features high-quality silicon-insulated wiring, professionally soldered and crimped to “Futaba”-style connectors, ensuring a secure, vibration-resistant connection between your RC receiver, flight controllers, and servos. Beyond aviation, these extensions are highly convenient for connecting 3-pin sensors to robotic controllers, providing reliable signal integrity and power delivery for complex mechatronic systems. With a robust 17cm length and twisted-pair construction to minimize electromagnetic interference, this cable ensures a rock-solid, interference-free connection every time.
Note: Product images are for reference only. The actual product may vary slightly in appearance or dimensions.
Key Features
- 22AWG Heavy-Duty Gauge: Thicker wire gauge provides lower electrical resistance, allowing for higher current capacity compared to standard servo leads.
- Twisted-Pair Construction: The twisted wire design effectively reduces electromagnetic interference (EMI), ensuring clean signal transmission in noisy electronic environments.
- High-Quality Futaba Connectors: Equipped with secure-fit male and female Futaba-style plugs for broad compatibility with RC receivers and servos.
- Durable Silicon Insulation: High-grade silicon jacketing remains flexible and heat-resistant, preventing cable fatigue during extreme temperature operation.
- Multi-Purpose Versatility: Ideal for RC aircraft, drone flight controllers (e.g., DJI Naza), robotics, and general-purpose 3-pin sensor integration.
Benefits
- Enhanced Reliability: Professional crimping and soldering ensure that connections remain secure under the high-vibration conditions of high-speed flight.
- Reduced Power Loss: The 22AWG conductor minimizes voltage drop across the length of the extension, ensuring your servos receive consistent voltage for optimal performance.
- Interference Protection: The twisted design provides a layer of protection against signal noise, keeping your control inputs accurate and responsive.
- Ease of Routing: The flexible nature of the high-quality silicon wire makes it easy to route through tight fuselage spaces or intricate robotic chassis.
- Long-Term Durability: Premium materials resist cracking and brittleness, extending the life of your wiring harness even with repeated plugging and unplugging.
Applications
- RC Aircraft & Gliders: Essential for extending control surface servos in large aircraft where standard leads may be too thin or too short.
- Drone Flight Controllers: Compatible with systems like DJI Naza and various multi-rotor flight control modules.
- Robotics & Automation: Provides a perfect, high-current connection for integrating 3-pin sensors and actuators with robot controllers.
- Power Distribution: Useful for distributing power and signals between RC receivers and motor controllers in custom builds.
- Test & Measurement: A reliable cable for quickly prototyping and validating 3-pin sensor circuits in research and development labs.
Package Includes
- 1 x SafeConnect Twisted 17cm Servo Lead Extension (Futaba-Style)
Specifications
| Parameter | Specification |
|---|---|
| Model Name | SafeConnect 17cm Servo Lead Extension |
| Connector Style | Futaba-Style (Male/Female) |
| Wire Gauge | 22 AWG |
| Length | 17 cm |
| Wiring Configuration | Red (Vcc), Black (Ground), White (Signal) |
| Compatibility | RC Servos, DJI Naza, 3-pin Sensors |
