Description
The KCD105-BSS_25 Rocker Switch is a premium electrical component that combines aesthetic elegance with robust mechanical performance. Featuring a sophisticated stainless steel finish and a sleek 25mm profile, this switch is designed to complement modern electronic enclosures while providing reliable power control.
The switch utilizes a user-friendly rocker-style mechanism, making it effortless to manage ON/OFF states in your circuits. Engineered for resilience, the KCD105-BSS_25 is built to operate reliably in diverse environmental conditions, including high-humidity settings (up to 95% RH at 40°C). With a rated capacity of 125V/10A and a tested lifespan of 10,000 cycles, it provides a stable and efficient solution for a wide range of electronic devices and professional systems.
Note: Product images are for reference only. The actual product may vary slightly in appearance or manufacturer markings depending on stock availability.
Key Features
- Stainless Steel Construction: Offers enhanced durability and a premium, professional appearance suitable for high-end hardware.
- Versatile 25mm Size: Optimized footprint for easy integration into standard panel cutouts and device housings.
- Resilient Operation: Designed to maintain performance in challenging environments, including temperatures from -25°C to +70°C and high-humidity conditions.
- High-Capacity Power Control: Rated for 125V AC at 10A, making it suitable for moderate power load applications.
- Long-Lasting Reliability: Tested for 10,000 operational cycles, ensuring consistent performance over the life of your equipment.
- User-Friendly Interface: Classic rocker geometry provides clear, intuitive, and tactile feedback for manual power control.
Benefits
- Aesthetic Appeal: The stainless steel finish adds a refined, durable touch to any control interface.
- Operational Versatility: Suitable for a wide range of indoor and controlled-environment applications.
- Safety and Integrity: High insulation resistance (>100MΩ) and low contact resistance (<0.05Ω) ensure clean power transfer and electrical safety.
- Reduced Maintenance: Robust construction and a long cycle life minimize the need for replacement in high-frequency use cases.
- Simple Assembly: Intuitive design allows for quick installation into new projects or as a direct replacement part.
Applications
- Consumer Electronics: Perfect for control panels on high-end household appliances and entertainment consoles.
- Laboratory Instrumentation: Reliable toggle for test equipment, diagnostic tools, and modular power boxes.
- Custom Prototyping: A premium choice for hardware engineers and makers building custom PC cases, audio amplifiers, or specialized controller boxes.
- Industrial Control Modules: Ideal for auxiliary power toggles in control cabinets and HMI interfaces.
- Smart Home Gear: Suitable for physical power controls on automated lighting systems or modular wall-mount units.
Package Includes
- 1 x ROCKER SWITCH KCD105-BSS_25
Specifications
| Parameter | Specification |
|---|---|
| Model (MPN) | KCD105-25 |
| Rated Voltage | 125V AC |
| Rated Current | 10A |
| Contact Resistance | < 0.05Ω |
| Insulation Resistance | > 100MΩ |
| Mechanical Lifespan | 10,000 Cycles |
| Operating Temperature | -25°C to +70°C |
| Humidity Tolerance | 95% RH (at 40°C) |
| Shipping Weight | 0.005 kg |
| Shipping Dimensions | 6 × 5 × 2 cm |
