SPIDER Automation Official Raspberry Pi Compute Module 5 IO Board | Development Baseboard | For CM5 Prototyping & Embedded Systems
Description
SPIDER Automation Official Raspberry Pi Compute Module 5 IO Board is an exceptionally versatile development platform and reference carrier designed to break out every interface available on the Compute Module 5. Whether you are prototyping a commercial product or building an advanced industrial controller, this baseboard provides the robust physical infrastructure needed to bring your design to life quickly and reliably.
Equipped with dual full-size HDMI 2.0 ports, high-speed USB 3.0 connectivity, dual MIPI DSI/CSI-2 camera/display ribbons, and an M.2 M-key PCIe slot for NVMe storage, it handles heavy computational workloads with ease. Complete with Gigabit Ethernet featuring PoE support and a standard 40-pin GPIO header, it delivers professional-grade flexibility for engineers, developers, and system integrators.
Key Features
- Comprehensive CM5 Breakout: Designed specifically to expose every vital interface and pin from the Compute Module 5.
- Dual Full-Size HDMI 2.0: Two standard HDMI ports supporting crystal-clear high-resolution dual-display configurations.
- High-Speed USB 3.0 Ports: Multiple USB ports enabling fast peripheral connections and data transfer rates.
- M.2 M-Key PCIe Expansion: Dedicated slot supporting fast NVMe solid-state drives and high-throughput add-on modules.
- Dual MIPI DSI / CSI-2: Advanced interfaces for connecting official Raspberry Pi touch displays and high-resolution cameras.
- Gigabit Ethernet with PoE: High-speed wired networking with Power-over-Ethernet capability (requires PoE HAT or compatible setup).
- Standard 40-Pin GPIO Header: Familiar pinout layout for seamless integration with existing Raspberry Pi hats and sensors.
- MicroSD Card Socket: Built-in storage card slot for alternative booting and system recovery options on non-emmc modules.
Benefits
- Accelerated Time-to-Market: Provides a ready-made reference design for rapid prototyping before custom carrier board production.
- Industrial-Grade Connectivity: Robust port selection ensures compatibility with standard industrial enclosures, displays, and peripherals.
- Flexible Storage Options: Combine module flash with fast M.2 NVMe SSDs for heavy database and server applications.
- Streamlined Power Delivery: Gigabit PoE support reduces cable clutter in permanent remote installations.
- Seamless Ecosystem Integration: Full compatibility with standard Raspberry Pi OS toolchains, libraries, and updates.
Applications
- Industrial Automation Gateways: Centralized factory floor controllers handling sensor inputs and machine vision.
- Commercial Digital Signage: Dual-screen multimedia players running high-definition video feeds.
- Advanced Edge AI & Vision Systems: High-speed processing units paired with cameras and local NVMe storage.
- Custom Network Appliances: High-throughput routers, firewalls, and local server nodes.
- Embedded IoT Hubs: Smart building automation and multi-protocol communication gateways.
Package Includes
- 1 x Official Raspberry Pi Compute Module 5 IO Board
Technical Specifications
| Parameter | Specification Details |
|---|---|
| Brand / Series | SPIDER Automation / Official Raspberry Pi Compute Module Range |
| Item / Component Type | Compute Module 5 Development IO Baseboard |
| Model Number / SKU | CM5 IO Board / SKU-SPIDER-OFFICIAL-RPI-CM5-IO-BOARD |
| Host Compatibility | Raspberry Pi Compute Module 5 (CM5) |
| GPIO Header | Standard 40-Pin GPIO Connector for Peripheral Expansion |
| Display & Video Outputs | 2 × Full-Size HDMI 2.0 Ports | Dual MIPI DSI / CSI-2 Connectors |
| USB & Data Interfaces | High-Speed USB 3.0 Ports & M.2 M-Key PCIe Slot |
| Networking | Gigabit Ethernet Port with PoE Support |
| Storage Support | MicroSD Card Socket & M.2 NVMe SSD Expansion |
| Package Shipping Weight | 0.20 kg |
| Package Shipping Dimensions | 13 cm × 9 cm × 3 cm |
