SPIDER Automation Microchip SAMA5D4 Xplained Ultra Evaluation Board offers engineers, developers, and embedded system designers an advanced, cost-effective platform to evaluate the SAMA5D4 Cortex-A5 microprocessor. Operating at 840 DMIPS, the SAMA5D4 MPU integrates an L2 cache and ARM NEON technology, making it exceptionally well-suited for high-performance, secure industrial applications, user interface (UI) terminals, and video playback devices.

The evaluation kit comes fully loaded with 512MB of DDR2 memory and 512MB of NAND flash. It supports comprehensive operating system ecosystems including Linux (via Linux4SAM with Yocto and Mainline support), Android, and bare-metal C software packages with rich example code. Outfitted with an HDMI output, LCD panel connectors, a 10/100 Ethernet port with a pre-programmed unique MAC address, multiple USB interfaces, and stackable Arduino R3 Shield / Xplained Wing headers, the SAMA5D4 Xplained Ultra streamlines the development of secure, connected embedded devices.

Key Features

• SAMA5D44 ARM Cortex-A5 MPU: High-performance 32-bit RISC processor operating at 840 DMIPS with hardware floating-point support.
• Advanced Security Features: Hardware-based security mechanisms designed to protect systems against counterfeiting, software theft, and ensure secure data transfer.
• High-Performance Memory Subsystem: Equipped with 512MB DDR2 RAM, 512MB NAND flash memory, and an L2 cache with ARM NEON™ support.
• Unique Network Identity: Onboard EEPROM pre-programmed with a unique MAC address and serial number for instant Ethernet plug-and-play.
• Versatile Display & Video Output: Features dedicated LCD connectors and an HDMI output port optimized for low-cost UI and video playback applications.
• Comprehensive USB Connectivity: Includes three USB ports configured as 2 Host ports and 1 Device port (which also supports board power and debugging).
• Dual Storage Expansion: Integrated with both SD/eMMC and MicroSD card slots for flexible file system deployment.
• Wired Networking: Onboard 10/100 Ethernet MAC with integrated physical transceiver (PHY) and standard RJ45 connector.
• Stackable Expansion Headers: Fully compatible with Arduino R3 Shield and Xplained Wing expansion modules for quick hardware customization.

Benefits

• Comprehensive OS & Bare-Metal Support: Out-of-the-box compatibility with Linux, Android, and bare-metal C development packages accelerates software design.
• Enhanced Data Security: Built-in cryptographic and security features safeguard sensitive industrial data and prevent unauthorized firmware copying.
• Accelerated HMI Development: Integrated HDMI, LCD ports, and video-capable core enable rapid prototyping of rich graphical operator touch panels.
• Zero-Configuration Network Setup: Factory-assigned unique MAC address eliminates manual networking hassles during laboratory and field testing.
• Extensive Peripheral Interfacing: Arduino and Xplained Wing compatibility allows immediate reuse of existing sensor and actuator expansion boards.

Applications

• Industrial HMI & Operator Terminals: Smart factory touch panels and control units requiring smooth graphical interfaces and secure data handling.
• Secure IoT Gateways: Connected edge hubs leveraging hardware security features and reliable Ethernet/USB networking.
• Consumer & Commercial Media Devices: Compact embedded systems utilizing video playback capabilities and HDMI display output.
• Embedded Systems R&D: Advanced educational and professional evaluation platform for ARM Cortex-A5 microprocessor architecture.

Package Includes

• 1 x Microchip SAMA5D4 Xplained Ultra Evaluation Board (SAMA5D44 Cortex-A5 MPU)
