SPIDER Automation Microchip ATmega328PB Xplained Mini Evaluation Kit | ATmega328PB 8-Bit Microcontroller
Description
SPIDER Automation Microchip ATmega328PB Xplained Mini Evaluation Kit provides engineers, developers, and embedded hobbyists with an effective evaluation platform for the 8-bit ATmega328PB microcontroller. Engineered for seamless prototyping, the kit features a fully integrated on-board debugger that links directly with Atmel Studio (version 6.2 and later) for comprehensive source-level debugging without requiring external programming hardware.
Designed to accelerate custom design integration, the Xplained Mini evaluation board exposes all signals and pins of the target MCU. It features automatic board identification for instant software recognition, an mEDBG status LED, a user-programmable yellow LED, and a mechanical push button, giving you an immediate interactive setup for developing robust microcontroller applications.
Key Features
- ATmega328PB Microcontroller: High-performance, low-power 8-bit megaAVR architecture core optimized for diverse embedded tasks.
- Integrated On-Board Debugger: Built-in debugging circuitry delivering full source-level debugging support in Atmel Studio.
- Automatic Board Identification: Auto-ID feature enables instant recognition and setup within compatible development environments.
- Full Signal Access: Comprehensive breakout pinouts providing direct access to all target microcontroller signals and interfaces.
- mEDBG Status LED: Dedicated green indicator light displaying real-time debugger and connection status.
- User-Programmable LED: Onboard yellow LED for quick visual feedback during testing and code execution.
- Mechanical Pushbutton: Integrated physical button for user input testing and interrupt handling.
- Seamless Software Integration: Native compatibility with modern versions of Atmel Studio for streamlined firmware development.
- Compact Prototyping Layout: Breadboard-friendly design ideal for modular testing and custom circuit integration.
- Cost-Effective Development Platform: Complete, ready-to-use evaluation kit tailored for rapid prototyping and educational use.
Benefits
- Out-of-the-Box Debugging: Integrated debugger eliminates the need for separate hardware programmers or complex wire setups.
- Accelerated Prototyping: Full signal breakout and onboard peripherals allow immediate testing of code logic and sensor interfaces.
- Streamlined Software Workflow: Auto-ID and native Atmel Studio support ensure a frictionless development experience.
- Flexible Custom Integration: Easily transition from evaluation board testing to custom PCB designs using the ATmega328PB architecture.
- Reliable Performance: Backed by Microchip/Atmel engineering standards for robust industrial and consumer applications.
Applications
- Embedded Systems Prototyping: Testing and developing firmware routines for 8-bit megaAVR microcontroller projects.
- IoT & Sensor Node Development: Creating smart monitoring devices utilizing serial, I2C, and SPI communication interfaces.
- Industrial Automation Logic: Small-scale control units, timer-based relay triggers, and data logging modules.
- Educational & R&D Training: Professional and academic platform for teaching embedded C programming and microcontroller architecture.
- Consumer Electronics & Gadgets: Custom hardware development for interactive appliances and DIY automation.
Package Includes
- 1 x Microchip ATmega328PB-XMINI Evaluation Kit (ATmega328PB Xplained Mini, 8-Bit)
Technical Specifications
| Parameter | Specification |
|---|---|
| Brand / Series | SPIDER Automation / Microchip Xplained Mini Series |
| Item Type | Microcontroller Evaluation Kit / Development Board |
| Model Order Code / SKU | ATMEGA328PB-XMINI / SKU-SPIDER-ATMEGA328PB-XMINI |
| Silicon Manufacturer | Microchip Technology (Atmel) |
| Silicon Family Name / Series | ATmega / megaAVR |
| Primary Silicon Core Number | ATmega328PB |
| Core Architecture | 8-Bit megaAVR RISC |
| Debugger Interface | On-board mEDBG with Atmel Studio Support & Auto-ID |
| Onboard Peripherals | 1 x Green mEDBG Status LED, 1 x Yellow User LED, 1 x Mechanical Push Button |
| Package Shipping Weight | 0.030 kg (30 g) |
| Package Shipping Dimensions | 9 cm × 7 cm × 3 cm |
