Description
The MCP4725A1T-E/CH from Microchip is a high-performance, single-channel, 12-bit Digital-to-Analog Converter (DAC) designed for precision applications requiring reliable voltage output. Featuring an industry-standard I²C interface, this DAC offers seamless connectivity for embedded systems and microcontrollers. The device is engineered to provide accurate signal conversion with low power consumption, making it an ideal component for a wide range of electronic designs.
Housed in a compact SOT-23 package, the MCP4725A1T-E/CH is perfect for space-constrained projects where both reliability and high resolution are critical. Whether you are generating analog waveforms, controlling voltage-sensitive components, or calibrating sensors, this DAC delivers consistent, high-quality results. Its integrated EEPROM allows for the storage of configuration settings and output values, ensuring that the device retains its state even after a power cycle.
Key Features
- 12-Bit Resolution: Provides high-precision digital-to-analog conversion for professional applications.
- I²C Interface: Industry-standard communication protocol for simplified system integration.
- Integrated EEPROM: Enables non-volatile storage of configuration and output values.
- Compact Packaging: Space-efficient SOT-23 (6-pin) surface-mount design.
- Wide Voltage Support: Operates efficiently across a supply range of 2.7V to 5.5V.
- Low Power Design: Optimized for efficiency in battery-powered and portable electronics.
- Versatile Performance: Ideal for precision control, signal synthesis, and programmable voltage generation.
Applications
- Industrial Automation: Precise voltage generation for control loops and actuators.
- Signal Processing: Accurate waveform generation for testing and measurement equipment.
- Sensor Calibration: Ideal for providing programmable bias voltages to sensors.
- Consumer Electronics: Versatile analog output for smart home devices, IoT hardware, and custom electronics.
Package Includes
- 1 x MCP4725A1T-E/CH 12-bit Digital to Analog Converter (SOT-23, 6-Pin)
Technical Specifications
| Parameter | Specification |
|---|---|
| Device Model | MCP4725A1T-E/CH |
| Resolution | 12-bit |
| Data Interface | I²C |
| Supply Voltage | 2.7V to 5.5V |
| Number of Pins | 6 Pins (SOT-23) |
| Shipping Weight | 0.01 kg |
| Shipping Dimensions | 4 × 4 × 1 cm |
Note: Product images are shown for illustrative purposes only and may differ from the actual product. For complete electrical characteristics, register maps, and application circuit diagrams, please refer to the official Microchip MCP4725 datasheet.
