Description
Enhance your Prusa Mini or Mini+ with the Bondtech Dual Drive extruder upgrade, meticulously designed to seamlessly integrate into the original setup. This upgrade empowers users to expand their printing capabilities by providing reliable filament feeding and compatibility with a wider range of materials.
Key Features
- Dual Drive Technology: Provides superior grip and reliable feeding for consistent extrusion.
- Filament Sensor Compatibility: Designed to work perfectly with the original Prusa Mini filament sensor setup.
- Adjustable Tension: Allows for fine-tuning the grip force to accommodate different filament types and stiffness.
- Expanded Material Compatibility: Enables the use of a wider range of materials compared to the stock extruder.
Applications
- High-Reliability Printing: Perfect for long print jobs where consistent filament feeding is critical to success.
- Flexible Material Handling: Improves performance when printing with TPU and other flexible filaments.
- Upgraded Performance: Ideal for users looking to enhance their Prusa Mini’s extrusion system without compromising compatibility.
Package Includes
- 1 x Bondtech IFS extruder for Prusa Mini
- 1 x 10076-4 IFS Magnet Holder (PA12)
- 1 x 10076-5 IFS Lever (PA12)
- 1 x 15112 IFS Extruder Plug (HT-PLA)
- 3 x Black nylon zip-ties
- 4 x M3x35 black oxide steel screws
- 1 x M3x12 black oxide steel screw
- 1 x Brass motor gear
- 1 x Thumb Screw assembly
Technical Specifications
| Parameter | Specification |
|---|---|
| Gear Ratio | 3:1 |
| Housing Material | SLS Printed parts in PA12 |
| E-steps Value | 415 |
| Hinge Type | Injection molded |
| Shipping Weight | 0.16 kg |
| Shipping Dimensions | 12 x 9 x 9 cm |
