Description
The AT24CM01-SSHD-B from Microchip is a high-density, 1-Mbit (131,072 × 8-bit) Serial Electrically Erasable PROM (EEPROM). Designed for performance and reliability, it utilizes the industry-standard 2-wire (I²C) serial interface, making it an excellent choice for applications requiring large amounts of persistent, non-volatile data storage, such as sensor logs, configuration settings, or system calibration parameters.
This device is optimized for efficiency, supporting a broad operating voltage range up to 5.5V, which ensures broad compatibility with diverse microcontroller architectures. Housed in a standard 8-pin SOIC surface-mount package, it provides a stable and space-optimized memory solution for industrial, communication, and consumer electronics that demand high-density storage in a compact footprint.
Key Features
- High Capacity: 1-Mbit density, organized as 131,072 × 8-bit.
- I²C Interface: Reliable 2-wire serial protocol for seamless communication.
- Wide Voltage Range: Supports operation up to 5.5V, accommodating varied power environments.
- High-Reliability: Optimized for long-term data retention and high-cycle read/write endurance.
- Compact SOIC-8 Package: Industry-standard surface-mount footprint for high-density PCB assembly.
Applications
- Data Logging: Ideal for storing extensive sensor datasets and operational histories.
- System Configuration: Persistent storage for device settings, network parameters, and user preferences.
- Embedded Systems: Suitable for industrial controllers, networking equipment, and portable hardware.
- Calibration Data: Secure, long-term storage for precision system calibration values.
Package Includes
- 1 x AT24CM01-SSHD-B EEPROM IC (SOIC-8)
Technical Specifications
| Parameter | Specification |
|---|---|
| Device | AT24CM01-SSHD-B |
| Memory Capacity | 1 Mbit (131,072 × 8-bit) |
| Interface | 2-Wire (I²C) |
| Mounting | Surface Mount |
| Shipping Weight | 0.001 kg |
| Shipping Dimensions | 4 × 4 × 1 cm |
Note: Product images are shown for illustrative purposes only and may differ from the actual product. For complete technical parameters, timing diagrams, and operating characteristics, please refer to the official Microchip datasheet.
