Description
The SPIDER Automation Amass XT30PB(2+2) Male Connector – XT30(2+2)PB-M.G.B is a compact electrical connector from the Amass XT30 series, designed for reliable power and signal connections in compact electronic and electrical systems. Its male configuration provides a compatible mating interface for the corresponding XT30-series female connector.
The connector uses a 2+2 contact configuration, providing primary power contacts together with an auxiliary signal contact. It is specified for 20A MAX with 16AWG wiring under the stated temperature condition, with the auxiliary signal contact specified at 1A.
With a 500V DC maximum voltage, IP40 protection level, 100×2 mechanical lifetime and UL94-V0 flammability rating, the XT30(2+2)PB-M.G.B provides a compact connector solution for applications where reliable power and signal connectivity are required.
Key Features
- XT30 Series: Part of the Amass XT30 family of electrical connectors.
- Male Configuration: Provides the male interface for compatible XT30-series mating connections.
- 2+2 Contact Configuration: Combines primary power contacts with auxiliary signal contacts.
- 20A Maximum Current: Rated for 20A MAX with 16AWG wiring under the specified condition.
- 1A Signal Contact: The auxiliary signal contact is specified for 1A.
- 500V DC Maximum Voltage: Supports compatible DC electrical systems within the specified voltage rating.
- Compact Construction: Provides a space-efficient connector solution for compact equipment.
- Secure Locking: Designed to maintain a secure mating connection during operation.
- IP40 Protection: Provides the specified protection level against solid foreign objects.
- UL94-V0 Flammability Rating: Provides the specified flame-retardant classification.
- Mechanical Lifetime: Rated for 100×2 mating cycles.
Benefits
- Combined Power & Signal Connectivity: Allows power and auxiliary signal contacts to be integrated into one connector interface.
- Space-Efficient Installation: Compact construction helps accommodate applications with limited available space.
- Defined Electrical Ratings: Clearly specified current and voltage ratings assist with compatible system selection.
- Secure Connection: The locking design helps maintain a stable connector interface during operation.
- Repeatable Mating: The 100×2 mechanical lifetime supports repeated connector connections.
- Defined Protection Characteristics: IP40 and UL94-V0 ratings provide clear protection and material classifications.
Applications
- Drone Systems: Suitable for compatible power and signal connection assemblies.
- RC Systems: Suitable for electrical power and signal connections in compatible remote-controlled equipment.
- Small Electric Vehicles: Suitable for compatible electrical connection applications within the specified ratings.
- Compact Electronic Systems: Useful where power and auxiliary signal connectivity are required in a compact format.
- Battery Assemblies: Suitable for compatible battery power and signal connection applications.
- Power & Signal Harnesses: Useful for wiring assemblies requiring combined power and auxiliary signal contacts.
Package Includes
- 1 × Amass XT30PB(2+2) Male Connector – XT30(2+2)PB-M.G.B
Technical Specifications
| Parameter | Specification |
|---|---|
| Brand | Amass |
| Product Type | Battery Connector |
| Model Series | XT30 |
| Model / Part Number | XT30(2+2)PB-M.G.B |
| Gender | Male |
| Contact Configuration | 2+2 |
| Rated Current | 20A MAX (16AWG / △<85°C) |
| Signal Contact Current | 1A |
| Maximum Voltage | 500V DC |
| Mechanical Lifetime | 100×2 cycles |
| Protection Level | IP40 |
| Flammability Rating | UL94-V0 |
| Shipping Weight | 0.002 kg |
| Shipping Dimensions (L × W × H) | 12 × 8 × 2 cm |
