Description
The 6A 250V DPST ON-OFF Rocker Switch is a premium power control component designed for efficiency, reliability, and ease of use. Engineered as a simple yet robust solution for power management, this switch features an intuitive snap-in design with integrated top and bottom mounting tabs, allowing for secure attachment to enclosures or control panels without the need for additional screws, nuts, or complex hardware.
This high-performance switch is ideal for controlling DC motors in robotics, automotive applications (cars and motorcycles), industrial machinery, and consumer devices like water dispensers. With a generous high load rating of 6A at 250V AC, it is built to handle the demands of most standard electrical environments. The rocker surface is clearly marked with “I” and “O” indicators, ensuring users can quickly and safely identify the switch’s state at a glance during operation.
Note: Product images are for reference only. The actual product may vary slightly in appearance or manufacturer markings depending on stock availability.
Key Features
- Screwless Snap-In Installation: Features integrated tabs that lock the switch securely into panel cut-outs, saving time and simplifying assembly.
- Clear Operational Feedback: Rocker surface is clearly marked with “I” and “O” for unambiguous identification of ON/OFF positions.
- High-Durability Construction: Engineered for an exceptional switching life, rated for between 50,000 and 100,000 cycles for long-term reliability.
- Versatile DPST Structure: Double-Pole, Single-Throw configuration allows for simultaneous control of two independent circuits.
- High Load Rating: Capable of handling up to 6A at 250V AC, making it a dependable choice for varied electrical loads.
- Professional Aesthetics: Classic black finish with a compact, modern profile that fits seamlessly into professional control consoles.
Benefits
- Efficient Assembly: Reduces installation time significantly by eliminating the requirement for mounting hardware or tools.
- Enhanced Operational Safety: Clearly marked positions prevent accidental toggling and allow for rapid status verification.
- Industrial-Grade Lifespan: Built to endure heavy usage cycles, ensuring your equipment remains functional without frequent component replacements.
- Flexible Power Routing: The DPST structure offers advanced control, enabling users to isolate both live and neutral lines for increased safety.
- Space-Optimized Design: The compact, lightweight form factor is perfect for projects where space is at a premium.
Applications
- Robotics & Automation: Essential for powering DC motors and control subsystems in custom robotic builds.
- Automotive & Marine: Highly suitable for controlling accessory circuits, auxiliary lighting, or motor systems in cars, motorcycles, and boats.
- Industrial Machinery: Reliable toggling component for modular machines, conveyors, and automated test benches.
- Home & Kitchen Appliances: A standard-setting switch for water dispensers, portable fans, and other household electronics.
- DIY Electronics: A go-to power switch for hardware engineers and hobbyists creating custom power strips or diagnostic equipment.
Package Includes
- 1 x 6A 250V DPST ON-OFF Rocker Switch
Specifications
| Parameter | Specification |
|---|---|
| Rating | Max 6A at 250V AC |
| Switching Mode | ON-OFF |
| Structure | DPST (Double-Pole, Single-Throw) |
| Panel Cut-Out | 22 x 20 x 12 mm |
| Material | Plastic and Metal |
| Color | Black |
| Dimensions | 24 (L) x 21 (W) x 25 (H) mm |
| Weight | 6g |
| Shipping Weight | 0.01 kg |
| Shipping Dimensions | 9 × 7 × 2 cm |
