Description
This is a 3mm Red DIP LED, designed for high-performance visual applications. An LED is a two-lead semiconductor light source that emits light when activated. When an appropriate voltage is applied to the terminals, electrons recombine with electron holes within the device, releasing energy in the form of photons through a process known as electroluminescence. The specific red color is determined by the energy bandgap of the semiconductor material.
These LEDs feature a 3mm round water-clear lens, making them perfect for applications ranging from status indication to specialized illumination projects. They are engineered for high efficiency, featuring low power consumption, long operational life, and super-bright output.
Features
- Design: 3mm Round Water Clear LED Lamp
- Versatility: Ideal for indication and general illumination
- Optics: 40-degree nominal viewing angle
- Durability: UV-resistant epoxy construction
- Efficiency: Low power consumption and long operational life
Package Includes
- 50 x 3mm Red DIP LED
Technical Specifications
| Parameter | Specification |
|---|---|
| Wavelength | 635 nm |
| Forward Voltage | 1.63 – 2.03 V |
| Viewing Angle | 30° |
| Brightness | 2500 MCD |
| Color | Red |
| Diameter | 3 mm |
| Weight (per unit) | 0.1 g (approx.) |
| Shipping Weight | 0.015 kg |
| Shipping Dimensions | 2 × 2 × 2 cm |
