Description
The 3.96-AWP 3.96mm Pitch 3-Pin Wafer Male Connector (MPN: 3.96-AWP) is a high-performance interconnect solution featuring a right-angle design, engineered for secure and reliable PCB-to-wire connections. Built to be Molex compatible, this connector facilitates space-saving, low-profile cable routing parallel to the circuit board. With a rated capacity of 7A and 250V AC/DC, it provides a stable electrical interface for power and signal distribution in diverse electronic and industrial systems.
Key Features
- Right-Angle Design: Facilitates efficient, low-profile cable management, ideal for compact electronic enclosures and stacked PCB assemblies.
- Molex Compatible: Designed for seamless interoperability with existing Molex-style systems, providing flexibility for your design and sourcing needs.
- High Power Capacity: Rated for 7A and 250V AC/DC, ensuring robust power delivery for demanding applications.
- Reliable Electrical Performance: Features high insulation resistance (1000MΩ) and low contact resistance (20mΩ), ensuring superior signal integrity and conductivity.
- Broad Temperature Range: Operates efficiently in harsh environments with an operating temperature range of -40°C to +85°C.
Applications
- PCB Assemblies: An essential component for creating robust right-angle headers for power and signal routing.
- Industrial Automation: Ideal for wiring harnesses in control equipment and automation hardware.
- Consumer Electronics: A dependable choice for internal connections requiring standardized, secure, and compact connectivity.
Package Includes
- 1 x 3.96-AWP 3.96mm Pitch 3-Pin Through-Hole Right-Angle Wafer Male Connector (Molex Compatible)
Technical Specifications
| Parameter | Specification |
|---|---|
| Item Type | Through-Hole Wafer Male Connector (Right-Angle) |
| Pitch | 3.96 mm |
| Number of Pins | 3 |
| Rated Voltage | 250 V AC/DC |
| Rated Current | 7 A AC/DC |
| Operating Temperature | -40°C to +85°C |
| Contact Resistance | 20 mΩ |
| Insulation Resistance | 1000 MΩ |
| Shipping Weight | 0.005 kg |
| Shipping Dimensions | 5 x 5 x 2 cm |
